Description

Highly effective decomposition of pollutants and nutrients, thanks to professional filter media and moving bed process (Moving Bed)
Mature, professional technology with more than 3 years of development time
Innovative and reliable product ?made in Germany? (except pressure pump)
Extremely large, protected settlement surface for micro-organisms (806 m?/m?)
Innovative bypass technology for optimal movement of the Hel-X bio-elements
Removal of toxins, such as ammonium / ammonia, nitrite and nitrate
50 l Hel-X decompose approx. 340 g of fish food per day (can be extended to 75 l / module).
Aerator bar for oxygen enrichment and turbulence already installed
Permanent, optimal oxygen supply; self-cleaning effect from dead biomass
Pulling the slide valve flushes the debris out via a DN 75 discharge

Technical Data

Dimensions (L x W x H)	mm	830 x 600 x 820
Net weight	kg	44.00
Guarantee (+ extended guarantee on request)	Years	2 + 1
Biological filter surface	m?	47.8
Biological filter surface protected	m?	40.3
Material		GRP Duroplast
Number of inlets	EA	2
Connection inlet	mm	180
Number of outlets	EA	2
Connections, outlet		DN 150
Connections, sludge discharge		DN 75
Min. flow rate	l/h	10000
Max. flow rate	l/h	33000
Connection to		AquaOxy CWS 2000 – 4800
Installation height above water level	cm	11.5
Type of use		Gravity fed system, Pump fed system
Other		Aeration pre-installed Pollutant discharge incl. slide valve incl. 50l Hel-X 13 Biomedia
Item number		50772
EAN		4010052507729
